JF84 auto clean dust collector with D50 accessories and continuous bagging — purple JFURTHER unit

JF84 Auto Clean Dust Collector — Continuous Bagging for Continuous Grinding

JF84 auto clean dust collector with continuous bagging for continuous grinding — 2.4 kW, 410 m³/h, automatic filter cleaning, H13 filtration at 0.3 μm.

Category: Maßgeschneiderter Staubabscheider, Industrieller Staubsauger

Key Facts

Model: JF84 — single-phase dust extractor with automatic cyclical filter cleaning (automatic reverse-air blowback).
Power and airflow: 2.4 kW (2 motors), max. airflow 410 m³/h, max. vacuum 220 mbar.
Filtration: two-stage PTFE membrane-coated cartridges, H13 at 0.3 μm, filter area 4.2 m².
Dust disposal: continuous bagging — pull down, cut and seal the bag without opening the tank.

Get a quote for the JF84 Auto Clean Dust Collector. Tell us your grinder model, voltage and country, and we will confirm the configuration and export packing within one business day. Please use the inquiry form on this page and include: (1) grinder brand and disc size, (2) voltage and plug standard, (3) quantity, (4) destination port, (5) manual or automatic cleaning preference.

Get a Quote

If you are still comparing models, see which dust extractor fits your grinder.

The JF84 is the dust extractor JFURTHER builds for contractors who grind concrete for long stretches and cannot afford to stop and clean filters. It is a 2.4 kW, two-motor, single-phase dust extractor with automatic cyclical filter cleaning: one motor’s filter is pulsed clean while the other keeps working, so suction stays steady throughout the shift. It delivers 410 m³/h of airflow and 220 mbar of vacuum — the same capacity as the manual JF82 — but it cleans itself.

A continuous bagging system handles disposal. Concrete and silica dust falls into one long transparent bag; you pull it down, cut it at any length and seal it, so the operator never tips an open drum of fine dust. An hour meter, forklift-friendly base and a height-compressible frame (approx. 1,155 mm packed height) keep fleet management and export shipping simple.

Automated cleaning cycle

The JF84 uses automatic cyclical filter cleaning: it automatically pulses reverse air back through one motor’s filter while the other motor keeps working, so suction is maintained. Each motor’s filter is cleaned in rotation, triggered automatically. You do not open the filter housing and you do not stop the grinder to clean filters.

H13 filtration

Two-stage membrane-coated cartridges filter dust down to 0.3 μm at H13 level, protecting operators during dry concrete grinding where respirable dust is the main hazard.

Continuous bagging

One long bag replaces fixed drums: pull, cut, seal, dispose. Faster changeovers and far less airborne dust during emptying.

Built to ship and to move

The frame compresses in height to cut freight volume, and the base can be lifted directly by forklift. Fitted castors handle day-to-day movement on site.

D50 accessories for floor clean-up

The standard D50 accessory kit is included: D50 x 7.5 m wear-resistant hose, aluminium S-wand, crevice tool and floor brush. An optional front suction bar (approx. 70 cm) speeds up final floor cleaning after grinding.

Technical Specifications

Power supply	Single-phase 220 V, 50 Hz (other voltages customizable)
Strom	2.4 kW (2 motors) — 2×1.2 kW at 220 V; 2×0.8 kW at 110 V
Max. vacuum	220 mbar
Max. airflow	410 m³/h at 220 V; 360 m³/h at 110 V
Filter cleaning	Automatic reverse-air blowback
Filter type	Two-stage high-efficiency membrane-coated cartridge
Filterfläche	4.2 m²
Filtration performance	H13 (0.3 μm)
Dust collection	Continuous bagging
Lärm	72±2 dBA
Dimensions (W×D×H)	800×530×1490 mm (compressed height approx. 1155 mm)
Zubehör	D50 standard kit
Gewicht	Approx. 90 kg

Confirm JF84 fits my grinder.

Industrial Vacuum Cleaner Video

Not the right fit if: you only grind intermittently and do not need automatic cleaning — the JF82 (manual, 410 m³/h) costs less and is simpler; if you need more airflow, choose the JF85 (620 m³/h, automatic) or the JF83 (620 m³/h, manual).

Häufig gestellte Fragen

Is the JF84 suitable for my grinder?

It suits small and mid-size concrete floor grinders used for continuous grinding. Send us your grinder model and disc size in the inquiry form and we will confirm the match before you order.

How does automatic filter cleaning work?

The JF84 uses automatic cyclical filter cleaning: it automatically pulses reverse air back through one motor’s filter while the other motor keeps working. Dust falls into the collection bag below. You do not open the filter housing and you do not stop the grinder to clean filters.

What is the difference between the JF82 and the JF84?

Both deliver 410 m³/h at 2.4 kW with H13 filtration at 0.3 μm and continuous bagging. The JF82 uses manual reverse-air cleaning (you clean the filter when suction drops); the JF84 cleans automatically on a cycle, so it suits longer continuous grinding.

Can the JF84 run on a different voltage?

Standard supply is single-phase 220 V, 50 Hz (2×1.2 kW, 410 m³/h). Other voltages can be customized, including 110 V (2×0.8 kW, 360 m³/h) — state your voltage and plug standard in your inquiry.

How is dust emptied?

Through the continuous bag: pull the bag down, cut and seal it. The dust stays enclosed, which reduces exposure during disposal.

Not sure which model? Send your grinder model — we reply with a recommendation, not just a price.
