JFL9 Compact Industrial Vacuum Cleaner
The three-phase Compact Industrial Vacuum Cleaner are characterized by fashion, simplicity, and manual vibration of dust. Compared with the other three-phase C5 series, they are more compact and capable of separating the upper and lower buckets, which makes it easy to clean the dust and waste. It can be used in electronic industrial processing, automation and other demanding occasions, and the size of the requirements of the occasion.
Weight | 50 kg |
---|---|
Dimensions | 54 × 92 × 85 cm |
Model | M912, M912-H |
Power Source(V/Hz) | Three Phase 380V / 50Hz |
Max. Negative Pressure(mBar) | 235mbar |
Maximum Air Volume(m3/h) | 265m3/h |
Filter Type | Bag filtration(external filtration) |
Dust Bucket Capacity(L) | 30 |
Model | JF9 |
Power Source(V/Hz) | Lithium Battery 24V/80AH |
Motor Power(KW) | 1.5kw |
Max. Negative Pressure(mBar) | 160 |
Maximum Air Volume(m3/h) | 420 |
Dust Vibrating Method | Blowback Vibration Dust |
Filter Type | Imported Polyester Fiber PTFE Coated Filter Barrel |
Filter Area(m2) | 30000 |
Filtration Performance | 0.3um, min≥99.5% |
Dust Bucket Capacity(L) | 65L |
Noise(dBA) | 78±2 |
Size(cm) | 610x670x1325 |
Weight(kg) | 85 |
- Power system adopts the international advanced precision casting turbine fan (air pump), wide pressure dual-frequency, high reliability, low noise, long life, maintenance-free 24-hour continuous work.
- The filtration system adopts star-shaped bag filter, polyester fiber needle felt substrate dust filtration accuracy of 5 microns, efficiency of more than 99%, in line with indoor emissions standards wind resistance, easy to clean up.
- Equipped with manual lifting and pulling dust vibration, easy to shake off the particles of dust adhering to the bag.
- Dust collecting barrel with upper and lower structure design, lateral design handle, bottom design universal casters.
- The product is equipped with a negative pressure monitoring table, always monitoring the negative pressure inside the barrel and alerting the operator.
Brief introduction
The JFL9 series of three-phase industrial vacuum cleaners dust collection are stylish, simple, and feature manual dust extraction. Compared with other three-phase dust collection, the JFL9 series of dust collection are shorter and can separate the upper and lower buckets, making it easy to clean the dust and waste. It can be used in electronic industrial processing, automation and other demanding occasions with high requirements on size.
JFL9 updated version, Optimize two points:
1, increase the bag vibration dust device.
2, increase the plugging pressure relief device.
Features
①Turbine motor, strong suction power, maintenance-free
Power system adopts international advanced precision casting turbine fan (air pump), wide pressure dual frequency, high reliability, low noise, long life, can be 24 hours continuous work. Power 2.2kw, power supply 380V/ 50Hz.
The dust collection is equipped with a motor limit load relief device to avoid and minimize motor failure due to prolonged filter clogging.
②Bag filter, simple and practical
The filtration system adopts star-shaped bag filter, polyester fiber needle felt substrate, dust filtration accuracy of 5 microns, efficiency of more than 99%, conform to indoor emission standards, small wind resistance, easy to clean. Configuration of manual swing vibration dust, effectively shake off the particles of dust attached to the bag.
③Dust collection bucket design: upper and lower bucket separation structure
The upper and lower structure of the dust bucket is designed in such a way that when cleaning up the dust bucket waste, the buckle can be opened to clean up the dust in the bucket. The dust bucket is designed with lateral handles and universal casters at the bottom, which is convenient for moving and transferring the dust bucket.
④Negative pressure monitoring, dust removal reminder
Negative pressure meter is the whole machine configuration components, detecting the clogging of the filter bag, bag clogging, negative pressure increases, the reading exceeds the alarm value, immediately carry out the ash cleaning or replacement.
⑤Industrial Casters
Front directional industrial casters, rear universal brake casters, easy to move and fix.
⑥ Optimized design
Rear design removable door plate, which is conducive to the maintenance and heat dissipation of the motor;
Rear design handle, conducive to the role of equipment movement and guidance.
⑦Dimension
Optional Accessories
7. Package
